What Humminbird units can be used on the Ultrex?

Thank you for contacting Minn Kota. Please refer to the web address below for guidance on determining compatibility with Dual Spectrum CHIRP (DSC), MEGA Down Imaging (MDI), MEGA Side Imaging (MSI), and Universal Sonar 2 (US2) built-in transducers. The guides below include compatibility information and required adapter cables for connecting Built-In Transducers to Humminbird, Garmin, and Lowrance units as well as units compatible with our Advanced GPS navigation system. Built-In Sonar/Transducer Connections and Compatibility Guide https://minnkota-help.johnsonoutdoors.com/hc/en-us/articles/26840163780375-Built-in-Sonar-Transducer-Connections-and-Compatibility Advanced GPS compatibility https://minnkota.johnsonoutdoors.com/us/support/compatibility/advanced-gps-navigation Minn Kota Technical Support

Will my Lowrance elite chirp 7 work with this trolling motor

Thank you for contacting Minn Kota. Please refer to the web address below for guidance on determining compatibility with Dual Spectrum CHIRP (DSC), MEGA Down Imaging (MDI), MEGA Side Imaging (MSI), and Universal Sonar 2 (US2) built-in transducers. The guide includes compatibility information and required adapter cables for connecting Built-In Transducers to Humminbird, Garmin, and Lowrance units. Built-In Sonar/Transducer Connections and Compatibility Guide https://minnkota-help.johnsonoutdoors.com/hc/en-us/articles/26840163780375-Built-in-Sonar-Transducer-Connections-and-Compatibility Minn Kota Technical Support

What are the dimensions of the bottom of the foot pedal. Trying to figure out if it will fit in my recessed tray

Thank you for your question regarding Minn Kota products. The base of the Ultrex foot pedal measures 12.5 inches long x 9 inches wide. Minn Kota Technical Support

Is there a power or heading light that comes on the control head when you step on the pedal

Thank you for your question regarding Minn Kota products. There is no such LED on the top head of the Ultrex QUEST. Minn Kota Technical Support

Does the Mega down imagining transducer also include dual spectrum chirp?

Thank you for your question regarding Minn Kota products. Yes, the built-in MDI transducer option is capable of displaying 2D CHIRP sonar. Minn Kota Technical Support

do I need to buy a heading sensor in order for the spot lock to work

Thank you for your question regarding Minn Kota products. Heading sensors are not used with QUEST model motors, as that technology is built internally into the GPS controller on the motor. The Ultrex QUEST is capable of Spot Lock out of the box upon completion of installation. Minn Kota Technical Support

Can you use litnomiem batterys1

Thank you for your question regarding Minn Kota products. Our permanent magnet, brushed motors can be run on lithium batteries with some stipulations. Please review the information in the following web address regarding the selection and use of lithium batteries. https://minnkota-help.johnsonoutdoors.com/hc/en-us/articles/6477037780631-Lithium-Battery-Selection-and-Recommendations Minn Kota Technical Support

have an ultrex 112 power light has a dim glow , motor come on for a split second , then nothing

Thank you for your question regarding Minn Kota products. A dim power light and/or a power light that goes off entirely is typically indicative of poor voltage to the motor. This could be due to batteries that are not holding a charge or voltage being lost through the power lead wires due to damage or poor connections. Minn Kota Technical Support

I want to purchase minn kato 80 trust without the transducer can I run the wireless remote

Thank you for your question regarding Minn Kota products. All Ultrex models include our Advanced GPS navigation system. As such, they can be operated remotely with the standard Advanced GPS wireless remote, Bluetooth Micro Remote, or via smartphone through the One Boat Network app. Minn Kota Technical Support

What adapter do I need for a helix. 10 to a ultrax

Thank you for contacting Minn Kota. Please refer to the web address below for guidance on determining compatibility with Dual Spectrum CHIRP (DSC), MEGA Down Imaging (MDI), MEGA Side Imaging (MSI), and Universal Sonar 2 (US2) built-in transducers. The guide includes compatibility information and required adapter cables for connecting Built-In Transducers to Humminbird, Garmin, and Lowrance units. Please note that current model Ultrexes come with the adapter cables to connect to compatible Humminbird units. Built-In Sonar/Transducer Connections and Compatibility Guide https://minnkota-help.johnsonoutdoors.com/hc/en-us/articles/26840163780375-Built-in-Sonar-Transducer-Connections-and-Compatibility Advanced GPS compatibility https://minnkota.johnsonoutdoors.com/us/support/compatibility/dual-spectrum-chirp Minn Kota Technical Support

Minn Kota Ultrex Trolling Motor, 24V, 80 lb, 45" Shaft, Humminbird Imaging-DSC, Micro Remote, Instant Response Foot Pedal

Overview

Minn Kota® Ultrex™ trolling motors give you the control and responsiveness needed to fish most effectively around cover and structure. Choose Ultrex for dependable brushed performance or Ultrex QUEST™ for brushless power. With precise foot pedal control and responsive steering with no lag or oversteer, Ultrex moves exactly where on the water you want it to. A clear transducer indicator keeps your live sonar aligned with your boat, so you can spend less time correcting your position and more time targeting fish. Plus, every Ultrex™ comes standard with everything needed to connect to select Humminbird® and Minn Kota® fish finders, bringing your Minn Kota trolling motor, shallow water anchors, and fish finder together in one seamless fishing system you can control through the Minn Kota Fishing App on iOs or Android™ devices.

FEATURES

Improved Spot-Lock®
Spot-Lock® gives you up to a 50% tighter hold to your spot and the power to stay right on top of any productive fishing spot with unparalleled GPS accuracy, so you can remain where you are without touching your trolling motor.

Intelligent Depth Control™
Avoid shallow water and protect your equipment—this feature detects depth changes, alerts you immediately, and takes action by automatically engaging Spot-Lock® and deploying your shallow water anchors.

Draw and Navigate™
Getting to your favorite spot is easier than ever. Just draw a course with your finger and the motor automatically takes you where you want to go.

Follow Mode
Keep your bait where the fish are by automatically following depth contours and weed lines.

Wireless Connectivity
From innovative navigation features to precise boat positioning, built-in connectivity let’s you wirelessly manage compatible gear seamlessly across your Minn Kota® system. Simplify the set up and use of your integrated system without complex rigging or cables—keeping everything connected, cleaner, and more organized.

One Seamless Fishing System
Minn Kota® trolling motors, fish finders, maps, sonar, and shallow water anchors all work together for one purpose—fishing. The Minn Kota® system seamlessly integrates what your fish finder sees with what your trolling motor does, turning sonar and mapping data into automated and precise boat positioning so you can stay focused on fishing.

Instant Response Steering
Easily maneuver to your spot with the most responsive and advanced foot pedal with heel to toe steering speed, a programmable button, Spot-Lock, and 6' cable.

Drift Mode
Spend more time fishing and less time fighting the conditions with precise GPS control of your drift path and speed. Drift Mode automatically engages speed and course control simultaneously—even in the heaviest wind and current.

Advanced GPS Trolling System
Use the most-trusted navigation system in fishing to keep you on the fish. Ultrex™ uses GPS to control your trolling motor with unrivaled features. Set Spot-Lock®, record paths, control speed and steering, and more. Minn Kota® makes boat positioning and control automatic, and you can take command from the easy-to-read LCD screen of Ultrex's wireless remote.

Industry-leading Sonar - Powered by Humminbird Imaging™ (DSC)
Unlock more fish, structure, and unprecedented underwater clarity with Dual Spectrum CHIRP sonar– providing exceptional 2D sonar with superior target separation. Built-In Dual Spectrum CHIRP Sonar covers a wide range of frequencies and keeps your transducer and wiring completely concealed and protected by running everything through the trolling motor's shaft.

Heel-Toe / Programmable Foot Pedal
Keep precise steering and your most-used feature at your feet with the only foot pedal offering Power Steering and a user-programmable button. Set it to mark a waypoint, engage AutoPilot™, or deploy and retract Minn Kota® shallow water anchors.

Lift-Assist
Stow and deploy your motor with half the effort using Ultrex's patented Lift-Assist design, featuring a stainless steel, nitrogen gas-charged spring.

Exceptionally Durable Composite Shaft
At the core of your Minn Kota® trolling motor is an exceptionally durable composite shaft, now made even stronger with carbon-fiber. It's a Minn Kota® exclusive, and we guarantee it for life.

Warranty
2 year limited warranty included, extended to 3 year limited warranty with product registration.

SPECS

General
Model	Minn Kota Ultrex Trolling Motor, 24V, 80 lb, 45" Shaft, Humminbird Imaging-DSC, Micro Remote, Instant Response Foot Pedal
For Use In	Freshwater
Mounting Location	Bow-Mount
Motor Style	Cable-steer
QUEST Series	No
Built-In Sonar	Dual Spectrum CHIRP
Product Code	1368833
UPC	0029402056361
Color	Black
Warranty	Three-Year Warranty with Registration
Dimensions & Weights
Shaft Length	45 in
Length	60 in \| 152.4 cm
Height	6 in \| 15.24 cm
Width	14 in \| 35.56 cm
Weight	64 lb 8 oz \| 29.2567 kg
Power & Propulsion
Max Thrust	80 lb
Voltage	24
Max Amp Draw	56
Speeds	Variable
Prop	Weedless Wedge 2 (MKP-33)
Battery Meter	Yes
Digital Maximizer	Yes
Mount Style	Mono-Arm
Control
One-Boat Network Compatible	Yes
Spot-Lock	Yes
CoPilot	No
AutoPilot	Yes
Foot Pedal Style	Heel-Toe / Cable
Power Steering	Yes
Control	Foot Pedal, Micro Remote
Wireless Remote	Yes
Auto Stow/Deploy	No
Bowguard	No
Power Trim	No
Lift-Assist	Yes
